Nutrunner
QX ZIGBEE AND BLUETOOTH, NO DISPLAY, 40V ANGLE 35 NM STANDARD SQUARE 3/8 INCH
IR QXXN5AT035PS06
IR QXXN5AT035PS06
3/8" 40V Cordless QX Precision Fastening Angle Torque Wrench, 310 in-lb Torque, 640 RPM
A member of the QX Connect Series Precision Fastening System, the 40V angle QXXN Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this angle wrench is designed to improve accuracy and productivity of your precision fastening and assembly operations. Reducing torque reaction doesn’t have to be complicated with the QX Connect Series Ergonomic Tightening System. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App.Features And Benefits
- Now Comes with 32 programmable tightening configuration.
- Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
- Enhanced quantitative feedback – displaying the actual measured torque or angle result.
- 1,200 cycles of onboard tightening data storage.
- Configurable preventative maintenance alarms.
- Intuitive qualitative feedback using Green, Red, and Yellow indicators.
- The QX Connect Series™ IQV40 high torque tools utilize the BL4011 40V 2.5Ah battery for increased torque and runtime. The BL4011 is optimum for longer use applications. The 40 volt batteries utilize our IQv Series 40V, 2.5Ah charger BC1161.
- Offer option for Insight Connect Android APP LINK.
- Optional ergonomic tightening system to reduce torque reaction experienced by operator.
- Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App; Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software.
Includes: Bare tool only; batteries and charger sold separately.
Actuation/Throttle Type/Switch Type: Trigger
Anvil Length: Standard
Built-in Light: No
Color: Grey
Configuration/Handle Type: Right Angle
Data Storage Capacity: 1200 cycles
Drive Size (in): 3/8
Drive Type: Square
Max Free Speed (rpm): 640
Max Torque (ft-lb): 26
Max Torque (in-lb): 310
Max Torque (nm): 35
Motor: Brushless Motor
Power Source: Battery Powered
Product Length (in): 22.91
Product Height (in): 3.94
Product Weight (lb): 4.8
Recommended Forward Torque Range (ft-lb): 5.2-26
Recommended Forward Torque Range (in-lb): 62-310
Recommended Forward Torque Range (nm): 7.0-35
Retainer Type: Pin Detent
Reversible: Reversible
Side to Center Distance (in): 0.68
Side to Center Distance (mm): 17
User Interface: No Display
Voltage DC: 40
Warranty: 1-year Tool, 2-year Battery, 3-year Charger
Wireless Tool Tracking: Bluetooth
Wireless Tool Tracking: 802.15.4
Wireless Tool Tracking: USB-C
Call for pricing
QX ZIGBEE AND BLUETOOTH, NO DISPLAY, 40V ANGLE 80 NM STANDARD SQUARE 1/2 INCH
IR QXXN5AT080PS08
IR QXXN5AT080PS08
1/2" 40V Cordless QX Precision Fastening Angle Torque Wrench, 708 in-lb Torque, 375 RPM
A member of the QX Connect Series Precision Fastening System, the 40V angle QXXN Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this angle wrench is designed to improve accuracy and productivity of your precision fastening and assembly operations. Reducing torque reaction doesn’t have to be complicated with the QX Connect Series Ergonomic Tightening System. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App.Features And Benefits
- Now Comes with 32 programmable tightening configuration.
- Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
- Enhanced quantitative feedback – displaying the actual measured torque or angle result.
- 1,200 cycles of onboard tightening data storage.
- Configurable preventative maintenance alarms.
- Intuitive qualitative feedback using Green, Red, and Yellow indicators.
- The QX Connect Series™ IQV40 high torque tools utilize the BL4011 40V 2.5Ah battery for increased torque and runtime. The BL4011 is optimum for longer use applications. The 40 volt batteries utilize our IQv Series 40V, 2.5Ah charger BC1161.
- Offer option for Insight Connect Android APP LINK.
- Optional ergonomic tightening system to reduce torque reaction experienced by operator.
- Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App; Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software.
Includes: Bare tool only; batteries and charger sold separately.
Actuation/Throttle Type/Switch Type: Trigger
Anvil Length: Standard
Built-in Light: No
Color: Grey
Configuration/Handle Type: Right Angle
Data Storage Capacity: 1200 cycles
Drive Size (in): 1/2
Drive Type: Square
Max Free Speed (rpm): 375
Max Torque (ft-lb): 59
Max Torque (in-lb): 708
Max Torque (nm): 80
Motor: Brushless Motor
Power Source: Battery Powered
Product Length (in): 23.07
Product Height (in): 3.94
Product Weight (lb): 5
Recommended Forward Torque Range (ft-lb): 8.9-59
Recommended Forward Torque Range (in-lb): 106-708
Recommended Forward Torque Range (nm): 12.0-80
Retainer Type: Pin Detent
Reversible: Reversible
Side to Center Distance (in): 0.85
Side to Center Distance (mm): 22
User Interface: No Display
Voltage DC: 40
Warranty: 1-year Tool, 2-year Battery, 3-year Charger
Wireless Tool Tracking: Bluetooth
Wireless Tool Tracking: 802.15.4
Wireless Tool Tracking: USB-C
Call for pricing
TT100I
STR 10015
STR 10015
Torque Transducers: QC Series
| Model | : | TT 100I | |
| Torque Range (nm) | : | 1.2-12 Nm | |
| Torque Range (in.lb) | : | 10-100 lbf in | |
| Male Hex | : | 1/4 in |
Product Description
- Quick Connect System that can be mounted to ML 1000 and ML 2000 Mechanical Loader
- Removal of adapter plate permits use with ML 250 (250 ft. lbs. capacity and below)
- Detachable cable (Part No: 10293) is required for all transducers
- TT-QC 25IO, TT-QC 1000 and TT-QC 2000 include detachable cable (Part No: 10293)
$3,484.57
KIT 2100PTA-45 NUT RUNNER 45NM
STR SRT12043
STR SRT12043
Power Tools Kits: 20V Angled Nut Runner Tool, Kit, 45 Nm
| Product Group | : | 20V Angled Nut Runner Tool, Kit, 45 Nm | |
| Model | : | 2100PTA-45K | |
| Capacity | : | 18-45 Nm | |
| Speed (RPM) | : | 210-300 | |
| Square Size | : | 3/8 in |
Product Description
- Brushless Motor - energy saving, higher efficiency and longer lasting
- Simple torque setting procedure
- Clutch operation reduces reaction force on operator
- LED indicators on tool providing OK/NOK status
- Double hit detection via measurement of fastener rotation
- Improved ergonomics and lightweight with Li-Ion compact battery
- Battery life indicator on the battery module
- Audible alerts to auto shut-off when torque reaches the set value
- Low maintenance costs due to long service life
- All torque and rotation measurements are programmable using the Global 400, Global 400MP or Global Manager Software
- 4 power tools can operate simultaneously with each control unit
- Accuracy of +/- 10%
- Kits include tool, 2 batteries, charger and adjustment tool
Call for pricing
