Fluid Regulators
REGULATOR, PRESS FLUID SST
GG 214706
GG 214706
REGULATOR, PRESS FLUID SST
Low Pressure Fluid Regulator, 250 Max psi, 5-100 psi Range, 3.0 GPM, SST, Spring Type, 3/8 (f) x 3/8 (f), 1/4 (f) Port Fluid pressure regulators control pressure of the downstream fluid, allowing operators to accurately control the pressure to guns, applicators and dispense valves Stainless steel wetted materials are compatible with catalyst and waterborne materials Removable adjustment key eliminates operator interference Manual quick flush mode ensures easy cleaning without impacting production settings Tungsten and carbide materials ensure low wear and long life PTFE/Elastomer hybrid diaphragm withstands wear while maintaining accurate responsiveness
$840.00
REGULATOR, BACK PRESSURE
GG 236770
GG 236770
REGULATOR, BACK PRESSURE
Graco 236770 Back Pressure Regulator, Low Pressure Mini, 180 Max psi, SST, Manual, 3/8 (m) x 3/8 (f), with Gauge
Back pressure regulators use closed loop control to maintain the pressure of the system regardless of flow demand
- Stainless steel wetted materials are compatible with catalyst and waterborne materials
- Tungsten and carbide materials ensure low wear and long life
- Compact and lightweight design saves space and reduces payload for small circulation systems
- Air operated model available for automated control, Conversion kit (237448)
- Compatible Material: Catalyst, Waterborne
- Gauge Port Size (cm): 0.635
- Gauge Port Size (in): 1/4
- Gauge Port Size (mm): 6.35
- Gauge Port Type: NPT
- Inlet Size (cm): 0.9525
- Inlet Size (in): 3/8
- Inlet Size (mm): 9.525
- Inlet Thread Type: NPSM
- Maximum Flow Rate (GPM): 4.3
- Maximum Flow Rate (L/min): 16.28
- Maximum Regulated Pressure (bar): 12.4
- Maximum Regulated Pressure (kPa): 1240
- Maximum Regulated Pressure (psi): 180
- Maximum Viscosity (cP): 1000
- Maximum Working Pressure (bar): 21
- Maximum Working Pressure (kPa): 2100
- Maximum Working Pressure (psi): 300
- Minimum Regulated Pressure (bar): 0.3
- Minimum Regulated Pressure (kPa): 30
- Minimum Regulated Pressure (MPa): 0.03
- Minimum Regulated Pressure (psi): 5
- Outlet Size (cm): 0.9525
- Outlet Size (in): 3/8
- Outlet Size (mm): 9.525
- Outlet Thread Type: NPSM
$997.00
REGULATOR, PRESSURE, FLUID
GG 238890
GG 238890
REGULATOR, PRESSURE, FLUID
Corrosion Resistant High Pressure Fluid Regulator, 500-3000 psi Range, 1.0 GPM, SST, Spring, 3/8(f) x 3/8(f), 1/4(f) Port, with gauge Stainless steel wetted materials are compatible with catalyst and waterborne materials Tungsten and carbide materials ensure low wear and long life Valve cartridge for quick cleaning and replacement – reduce downtime Glycerin filled gauge for accurate pressure reading
$1,365.00
REGULATOR, MASTIC
GG 903958
GG 903958
REGULATOR, MASTIC
Graco 903958 Spring Operated Mastic Fluid Pressure Regulator
The mastic regulator is ideal for low to high viscosity sealants or adhesives
Application: These regulators control downstream pressure for mastic or semi-solid material. Install a regulator ahead of each spray gun or extruder gun in a multiple outlet system. The regulator provides precise pressure control to each spray gun from a common header system. It also dampens flow surges when line valves are opened and during pump stroke changeover.- Actuation Type: Spring
- Flow Control Type: Regulation
- Gauge Port Size (cm): 1.905
- Gauge Port Size (in): 3/4
- Gauge Port Size (mm): 19.05
- Gauge Port Type: NPT
- Inlet Size (cm): 1.905
- Inlet Size (in): 3/4
- Inlet Size (mm): 19.05
- Inlet Thread Type: NPT
- Maximum Regulated Pressure (bar): 310
- Maximum Regulated Pressure (kPa): 31000
- Maximum Regulated Pressure (MPa): 31.0
- Maximum Regulated Pressure (psi): 4500
- Maximum Viscosity (cP): 80000
- Maximum Working Pressure (bar): 344
- Maximum Working Pressure (kPa): 34400
- Maximum Working Pressure (MPa): 34.4
- Maximum Working Pressure (psi): 5000
- Minimum Regulated Pressure (bar): 70
- Minimum Regulated Pressure (kPa): 7000
- Minimum Regulated Pressure (MPa): 7.0
- Minimum Regulated Pressure (psi): 1000
- Outlet Size (cm): 1.905
- Outlet Size (in): 3/4
- Outlet Size (mm): 19.05
- Outlet Thread Type: NPT
$2,550.00
REGULATOR, PRESS, FLUID
GG 217314
GG 217314
REGULATOR, PRESS, FLUID
Graco 217314 Low Pressure Fluid Regulator, 250 Max psi, 20-160 psi Range, 3.0 GP (m), SST, Spring Type, 3/8 (f) x 3/8 (f), 1/4 (f) Port
Fluid pressure regulators control pressure of the downstream fluid, allowing operators to accurately control the pressure to guns, applicators and dispense valves
- Stainless steel wetted materials are compatible with catalyst and waterborne materials
- Removable adjustment key eliminates operator interference
- Manual quick flush mode ensures easy cleaning without impacting production settings
- PTFE/Elastomer hybrid diaphragm withstands wear while maintaining accurate responsiveness
- Actuation Type: Spring
- Gauge Port Size (cm): 0.635
- Gauge Port Size (in): 1/4
- Gauge Port Size (mm): 6.35
- Gauge Port Thread Gender: Female
- Gauge Port Type: NPT
- Includes: Gauge
- Inlet Size (cm): 0.9525
- Inlet Size (in): 3/8
- Inlet Size (mm): 9.525
- Inlet Thread Gender: Female
- Inlet Thread Type: NPT
- Maximum Flow Rate (GPM): 3
- Maximum Flow Rate (L/min): 11.36
- Maximum Regulated Pressure (bar): 11
- Maximum Regulated Pressure (kPa): 1100
- Maximum Regulated Pressure (MPa): 1.1
- Maximum Regulated Pressure (psi): 160
- Maximum Viscosity (cP): 1000
- Maximum Working Pressure (bar): 18
- Maximum Working Pressure (kPa): 1800
- Maximum Working Pressure (MPa): 1.8
- Maximum Working Pressure (psi): 250
- Minimum Regulated Pressure (bar): 1.4
- Minimum Regulated Pressure (kPa): 140
- Minimum Regulated Pressure (MPa): 0.14
- Minimum Regulated Pressure (psi): 20
- Outlet Size (cm): 0.9525
- Outlet Size (in): 3/8
- Outlet Size (mm): 9.525
- Outlet Thread Gender: Female
$1,185.00
REGULATOR, PRESS, FLUID, 0-60 PSI
GG 241976
GG 241976
REGULATOR, PRESS, FLUID, 0-60 PSI
Graco 241976 Low Pressure Lightweight Fluid Regulator, 3-30 psi (0.2-2 bar), 0.5 gpm, Acetal, Air, 1/4(f) x 1/4(f), 1/4(f) Port
Fluid pressure regulators control pressure of the downstream fluid, allowing operators to accurately control the pressure to guns, applicators and dispense valves
- Lightweight composite material is compatible with waterborne materials
- PTFE, stainless steel seat, and carbide ball provide wear resistance
- Pressure adjustment key with locking mechanism protects production settings
- Actuation Type: Spring
- Gauge Port Size (cm): 0.635
- Gauge Port Size (in): 1/4
- Gauge Port Size (mm): 6.35
- Gauge Port Type: NPT
- Includes: Regulator Only
- Inlet Size (cm): 0.635
- Inlet Size (in): 1/4
- Inlet Size (mm): 6.35
- Inlet Thread Type: NPT
- Maximum Flow Rate (GPM): 0.5
- Maximum Flow Rate (L/min): 1.89
- Maximum Regulated Pressure (bar): 2.1
- Maximum Regulated Pressure (kPa): 210
- Maximum Regulated Pressure (MPa): 0.21
- Maximum Regulated Pressure (psi): 30
- Maximum Viscosity (cP): 1000
- Maximum Working Pressure (bar): 7
- Maximum Working Pressure (kPa): 700
- Maximum Working Pressure (MPa): 0.7
- Maximum Working Pressure (psi): 100
- Minimum Regulated Pressure (bar): 0.2
- Minimum Regulated Pressure (kPa): 20
- Minimum Regulated Pressure (MPa): 0.02
- Minimum Regulated Pressure (psi): 3
- Outlet Size (cm): 0.635
- Outlet Size (in): 1/4
- Outlet Size (mm): 6.35
$685.00
D/S Regulator, 3/8In, Alu, 0-60 psi
GG 203831
GG 203831
REGULATOR,FLUID
Graco 203831 Low Pressure Fluid Regulator, 0-60 psi (0-4 bar) Regulated Pressure, 3.0 GPM, Aluminum, Spring Type, 3/8(f) x 3/8(m), 1/4(f) Port
For accurate, positive control of fluid pressure to one spray gun, dispensing valve, or atomizing head. Gives positive control of fluid pressures in most normal direct supply and circulating spray systems
$831.00
REGULATOR, MASTIC, 5000 PSI
GG 961635
GG 961635
REGULATOR, MASTIC, 5000 PSI
Graco 961635 Air Operated Mastic Fluid Pressure Regulator
The mastic regulator is ideal for low to high viscosity sealants or adhesives
Application: These regulators control downstream pressure for mastic or semi-solid material. Install a regulator ahead of each spray gun or extruder gun in a multiple outlet system. The regulator provides precise pressure control to each spray gun from a common header system. It also dampens flow surges when line valves are opened and during pump stroke changeover.- Actuation Type: Air
- Flow Control Type: Regulation
- Gauge Port Size (cm): 1.905
- Gauge Port Size (in): 3/4
- Gauge Port Size (mm): 19.05
- Gauge Port Type: NPT
- Inlet Size (cm): 1.905
- Inlet Size (in): 3/4
- Inlet Size (mm): 19.05
- Inlet Thread Type: NPT
- Maximum Regulated Pressure (bar): 310
- Maximum Regulated Pressure (kPa): 31000
- Maximum Regulated Pressure (MPa): 31.0
- Maximum Regulated Pressure (psi): 4500
- Maximum Viscosity (cP): 80000
- Maximum Working Pressure (bar): 344
- Maximum Working Pressure (kPa): 34400
- Maximum Working Pressure (MPa): 34.4
- Maximum Working Pressure (psi): 5000
- Minimum Regulated Pressure (bar): 17
- Minimum Regulated Pressure (kPa): 1700
- Minimum Regulated Pressure (MPa): 1.7
- Minimum Regulated Pressure (psi): 250
- Outlet Size (cm): 1.905
- Outlet Size (in): 3/4
- Outlet Size (mm): 19.05
- Outlet Thread Type: NPT
$2,890.00
REGULATOR, PRESSURE, NPT, P60-VP DN7
GG 234266
GG 234266
REGULATOR, PRESSURE, NPT, P60-VP DN7
Graco 234266 High Pressure Fluid Regulator, 5000 Max psi, 70-900 psi Range, 11.3 GPM, SST, Air Type, 3/4 (f) x 3/4 (f), 1/4 BSPP Port
Our pneumatically operated fluid pressure regulators are designed primarily for use with highly viscous coatings
- Actuation Type: Air
- Gauge Port Size (cm): 0.635
- Gauge Port Size (in): 1/4
- Gauge Port Size (mm): 6.35
- Gauge Port Type: BSPP
- Includes: Regulator Only
- Inlet Size (cm): 1.905
- Inlet Size (in): 3/4
- Inlet Size (mm): 19.05
- Inlet Thread Type: NPT
- Maximum Flow Rate (GPM): 11.3
- Maximum Flow Rate (L/min): 42.8
- Maximum Regulated Pressure (bar): 60
- Maximum Regulated Pressure (kPa): 6000
- Maximum Regulated Pressure (MPa): 6
- Maximum Regulated Pressure (psi): 900
- Maximum Working Pressure (bar): 360
- Maximum Working Pressure (kPa): 36000
- Maximum Working Pressure (MPa): 36
- Maximum Working Pressure (psi): 5000
- Minimum Regulated Pressure (bar): 5
- Minimum Regulated Pressure (kPa): 500
- Minimum Regulated Pressure (MPa): 0.5
- Minimum Regulated Pressure (psi): 70
- Outlet Size (cm): 1.905
- Outlet Size (in): 3/4
- Outlet Size (mm): 19.05
$2,270.00
REGULATOR, FLUID, 1:1 RATIO
GG 24C375
GG 24C375
REGULATOR, FLUID, 1:1 RATIO
1:1 Precision Flow Fluid Pressure Regulator, 90 psi (6.2 bar) max pressure, silver ratio spacer Fluid regulators keep your system functioning more productively. Available with mechanical control or pneumatic control Suitable for fluids with low and high viscosities Models available with wetted parts made of stainless steel Application-oriented pressure ranges
$2,190.00
VALVE, BACK PRESSURE
GG 206819
GG 206819
VALVE, BACK PRESSURE
Back Pressure Fluid Regulator, 3000 Max psi, CS, Spring Type, 1/4 (f) x 1/4 (f) Back pressure regulators use closed loop control to maintain the pressure of the system regardless of flow demand Tungsten and carbide materials ensure low wear and long life Plated carbon steel housing is compatible with solvent-bornematerials Laser-marked indication lines for easy pressure adjustmentand process control Ergonomic adjustment knob
$1,530.00
Fluid Regulator, Low Pressure (0-15 Lbs), Ss
BB 84-410
BB 84-410
Fluid Regulator, Low Pressure (0-15 Lbs), Ss
$944.00
D/S Regulator, 3/8In, Alu, 20-160 psi
GG 204501
GG 204501
D/S Regulator, 3/8In, Alu, 20-160 psi
$979.00
REGULATOR, PRESS, FLUID
GG 236449
GG 236449
REGULATOR, PRESS, FLUID
Graco 236449 Low Pressure Lightweight Fluid Regulator, Gauge, 3-30 psi (0.2-2 bar), 0.5 gpm, Acetal, Spring, 1/4(f) x 1/4(f), 1/4(f) Port
Fluid pressure regulators control pressure of the downstream fluid, allowing operators to accurately control the pressure to guns, applicators and dispense valves
- Lightweight composite material is compatible with waterborne materials
- PTFE, stainless steel seat, and carbide ball provide wear resistance
- Pressure adjustment key with locking mechanism protects production settings
- Actuation Type: Spring
- Gauge Port Size (cm): 0.635
- Gauge Port Size (in): 1/4
- Gauge Port Size (mm): 6.35
- Gauge Port Type: NPT
- Includes: Gauge
- Inlet Size (cm): 0.635
- Inlet Size (in): 1/4
- Inlet Size (mm): 6.35
- Inlet Thread Type: NPT
- Maximum Flow Rate (GPM): 0.5
- Maximum Flow Rate (L/min): 1.89
- Maximum Regulated Pressure (bar): 2.1
- Maximum Regulated Pressure (kPa): 210
- Maximum Regulated Pressure (MPa): 0.2
- Maximum Regulated Pressure (psi): 30
- Maximum Viscosity (cP): 1000
- Maximum Working Pressure (bar): 7
- Maximum Working Pressure (kPa): 700
- Maximum Working Pressure (MPa): 0.7
- Maximum Working Pressure (psi): 100
- Minimum Regulated Pressure (bar): 0.2
- Minimum Regulated Pressure (kPa): 20
- Minimum Regulated Pressure (MPa): 0.02
- Minimum Regulated Pressure (psi): 3
- Outlet Size (cm): 0.635
- Outlet Size (in): 1/4
- Outlet Size (mm): 6.35
$684.00
Fluid Regulator, Hi-Capacity (0-100 Lbs)
BB 84-411
BB 84-411
Fluid Regulator, Hi-Capacity (0-100 Lbs)
$870.00
REGULATOR, FLUID PRESS
GG 214895
GG 214895
REGULATOR, FLUID PRESS
Low Pressure Fluid Regulator, 250 Max psi, 5-100 psi Range, 3.0 GPM, SST, Spring Type, 3/8 (f) x 3/8 (f), 1/4 (f) Port Fluid pressure regulators control pressure of the downstream fluid, allowing operators to accurately control the pressure to guns, applicators and dispense valves Stainless steel wetted materials are compatible with catalyst and waterborne materials Removable adjustment key eliminates operator interference Manual quick flush mode ensures easy cleaning without impacting production settings Tungsten and carbide materials ensure low wear and long life PTFE/Elastomer hybrid diaphragm withstands wear while maintaining accurate responsiveness
$774.00
REGULATOR, PRESS, FLUID
GG 236450
GG 236450
REGULATOR, PRESS, FLUID
Graco 236450 Low Pressure Lightweight Fluid Regulator, Gauge, 20-100 psi (1-7 bar), 0.5 gpm, Acetal, Spring, 1/4(f) x 1/4(f), 1/4(f) Port
Fluid pressure regulators control pressure of the downstream fluid, allowing operators to accurately control the pressure to guns, applicators and dispense valves
- Lightweight composite material is compatible with waterborne materials
- PTFE, stainless steel seat, and carbide ball provide wear resistance
- Pressure adjustment key with locking mechanism protects production settings
- Actuation Type: Spring
- Gauge Port Size (cm): 0.635
- Gauge Port Size (in): 1/4
- Gauge Port Size (mm): 6.35
- Gauge Port Type: NPT
- Includes: Gauge
- Inlet Size (cm): 0.635
- Inlet Size (in): 1/4
- Inlet Size (mm): 6.35
- Inlet Thread Type: NPT
- Maximum Flow Rate (GPM): 0.5
- Maximum Flow Rate (L/min): 1.89
- Maximum Regulated Pressure (bar): 7.0
- Maximum Regulated Pressure (kPa): 700
- Maximum Regulated Pressure (MPa): 0.7
- Maximum Regulated Pressure (psi): 100
- Maximum Viscosity (cP): 1000
- Maximum Working Pressure (bar): 7
- Maximum Working Pressure (kPa): 700
- Maximum Working Pressure (MPa): 0.7
- Maximum Working Pressure (psi): 100
- Minimum Regulated Pressure (bar): 1.4
- Minimum Regulated Pressure (kPa): 140
- Minimum Regulated Pressure (MPa): 0.14
- Minimum Regulated Pressure (psi): 20
- Outlet Size (cm): 0.635
- Outlet Size (in): 1/4
- Outlet Size (mm): 6.35
$579.00
Payment options
