Torque Control

IR QE6SE050F41S08

DC Q-Series QE6 Motor, Inline 50 Nm

IR QTA040

Bench-mounted Torque Reaction Arm, 25" Reach, 40 NM Torque, 17.5" Vertical Travel Distance, 6.5 LB Weight Capacity, 39.7"H

Ingersoll Rand QTA Series bench-mounted torque reaction arms are constructed of lightweight aluminum. They include an Ingersoll Rand spring-loaded, die-cast aluminum balancer for impressive strength and reduced weight.

Features And Benefits

• Spring balancer adjusts easily and offers effortless vertical movement.
• Simple, proven design for trouble-free setup and dependability.
• Anodized aluminum body delivers toughness in a lightweight design.
• Chrome-plated pole paired with a self-lubricating bearing, provides unmatched durability.
• Adjustable reach for easy use and convenience when locating fasteners.
• Multiple-tool holder options include right angle, swivel, and pistol grip.
• Cable or air line clamps keep work area clear and organized.
• Custom tool holder options enable seamless integration with Ingersoll Rand QA and QE tools.
• Position arm at 90-degree angle for optimum torque reaction performance. Arm should not be used in fully extended or fully collapsed position as this reduces reaction capabilities.

Includes: tool holder and spring balancer
Product Application and Uses: For use with assembly tools.

IR RTS060PH6-K2

RTS 3/8" 20V Mechanical Cordless Pulse Tool 2 Battery Kit, 44ft-lb Torque, 3600PPM, 2700RPM, Hog Ring/Thru-Hole Retainer

RTS Responsive Tightening System - Transform assembly lines with the RTS Connect, where responsive action meets torque control. Infused with Ingersoll Rand® torque control algorithm, this system is a game changer for reliable tightening. Experience effortless operations with its user-friendly interface, 40 distinct torque levels, seven flush levels and dual speed non-contact trigger and a 360° status beam LED ring light. The RTS Connect features reactionless performance, combined with robust wireless connectivity and programmable settings, making it the tool of choice for those who demand perfection at every turn.

Features And Benefits

• SIMPLE: An integrated color LCD display is an easy-to-use interface that streamlines the setup process and delivers key insights to the operator. The multi-color 360° status beam LED ring light illuminates the work area and offers clear feedback to the operator on the cycle status. 3 programming methods provide faster and smarter configuration. (Basic setup via the tool display, Advanced setup via INSIGHT™ Connect controller or mobile app, Expert setup via INSIGHTqcx™ MTC controller)
• FLEXIBLE: Up to 8 P-set configurations reduce the need for multiple tools for different applications on the assembly line. Compatible with IQV20™ battery and charger platform, providing flexibility and reducing costs in operations. 4 communication options available to adapt to evolving connectivity requirements. (Wi-Fi 2.4 and 5 Ghz, Radio (802.15.4), Bluetooth, USB-C)
• CAPABLE: Proprietary torque control algorithm that delivers consistent, repeatable fastening every time. 40 torque settings and 7 flush detection levels to adapt to various application types. Multi-tool connection, with up to 16 tools wirelessly connected to the INSIGHTqcx™ MTC controller, reduces the hardware footprint.
• ERGONOMICS: RTS Connect tools eliminate torque reaction, have best-in-class tool balance & ergonomic grip design, and their light weight design significantly reduces operator fatigue.
• KIT INCLUDES: 3/8" RTS Pulse Tool, (2) 2.5 Ah Batteries, Charger.

Includes: 3/8" RTS Pulse Tool, (2) 2.5 Ah Batteries, Charger.
Product Application and Uses: For use in product environments on assembly lines.
Anvil Length: Standard
Built-in Light: Yes
Color: Grey
Configuration/Handle Type: Pistol Grip
Data Storage Capacity: 1200 cycles
Drive Size (in): 3/8
Drive Type: Square
Duty Rating: Production Environment
Fastener Size: M8-M10
Housing Material: Glass-filled Nylon (PA6-GF30)
Lumens: 11
Max Free Speed (rpm): 2700
Motor: Brushless Motor
Number of Batteries Required: 1
Power Source: Battery Powered
Product Length (in): 6.46
Product Weight (lb): 2.35
Product Weight (lb) (with Battery): 3.26
Pulses per Minute: 3600
Recommended Forward Torque Range (ft-lb): 8.9-44
Recommended Forward Torque Range (in-lb): 106-531
Recommended Forward Torque Range (nm): 12-60
Retainer Type: Friction Ring and Thru-hole
Reversible: Reversible
Sound Pressure/Power Db(A): 94 / 102
Vibration Level (m/s2): 10.5
Vibration Uncertainy K* (m/s2): 1.8
Voltage DC: 20
Warranty: 1-year Tool, 2-year Battery, 3-year Charger
Wireless Tool Tracking: Bluetooth
Wireless Tool Tracking: 802.15.4
Wireless Tool Tracking: 2.4 GHz Wi-Fi
Wireless Tool Tracking: 5 GHz Wi-Fi
Wireless Tool Tracking: USB-C

IR RTS140PH8-K2

RTS 1/2" 20V Mechanical Cordless Pulse Tool 2 Battery Kit, 103ft-lb Torque, 3600PPM, 2700RPM, Hog Ring/Thru Hole Retainer

RTS Responsive Tightening System - Transform assembly lines with the RTS Connect, where responsive action meets torque control. Infused with Ingersoll Rand® torque control algorithm, this system is a game changer for reliable tightening. Experience effortless operations with its user-friendly interface, 40 distinct torque levels, seven flush levels and dual speed non-contact trigger and a 360° status beam LED ring light. The RTS Connect features reactionless performance, combined with robust wireless connectivity and programmable settings, making it the tool of choice for those who demand perfection at every turn.

Features And Benefits

• SIMPLE: An integrated color LCD display is an easy-to-use interface that streamlines the setup process and delivers key insights to the operator. The multi-color 360° status beam LED ring light illuminates the work area and offers clear feedback to the operator on the cycle status. 3 programming methods provide faster and smarter configuration. (Basic setup via the tool display, Advanced setup via INSIGHT™ Connect controller or mobile app, Expert setup via INSIGHTqcx™ MTC controller)
• FLEXIBLE: Up to 8 P-set configurations reduce the need for multiple tools for different applications on the assembly line. Compatible with IQV20™ battery and charger platform, providing flexibility and reducing costs in operations. 4 communication options available to adapt to evolving connectivity requirements. (Wi-Fi 2.4 and 5 Ghz, Radio (802.15.4), Bluetooth, USB-C)
• CAPABLE: Proprietary torque control algorithm that delivers consistent, repeatable fastening every time. 40 torque settings and 7 flush detection levels to adapt to various application types. Multi-tool connection, with up to 16 tools wirelessly connected to the INSIGHTqcx™ MTC controller, reduces the hardware footprint.
• ERGONOMICS: RTS Connect tools eliminate torque reaction, have best-in-class tool balance & ergonomic grip design, and their light weight design significantly reduces operator fatigue.
• KIT INCLUDES: 1/2" RTS Pulse Tool, (2) 2.5 Ah Batteries, Charger.

Includes: 1/2" RTS Pulse Tool, (2) 5.0 Ah Batteries, Charger.
Product Application and Uses: For use in product environments on assembly lines.
Anvil Length: Standard
Built-in Light: Yes
Color: Grey
Configuration/Handle Type: Pistol Grip
Data Storage Capacity: 1200 cycles
Drive Size (in): 1/2
Drive Type: Square
Duty Rating: Production Environment
Fastener Size: M10-M14
Housing Material: Glass-filled Nylon (PA6-GF30)
Lumens: 11
Max Free Speed (rpm): 2700
Motor: Brushless Motor
Number of Batteries Required: 1
Power Source: Battery Powered
Product Length (in): 6.69
Product Weight (lb): 2.42
Product Weight (lb) (with Battery): 3.32
Pulses per Minute: 3600
Recommended Forward Torque Range (ft-lb): 22-103
Recommended Forward Torque Range (in-lb): 266-1239
Recommended Forward Torque Range (nm): 30-140
Retainer Type: Friction Ring and Thru-hole
Reversible: Reversible
Sound Pressure/Power Db(A): 95 / 103
Vibration Level (m/s2): 11
Vibration Uncertainy K* (m/s2): 1.6
Voltage DC: 20
Warranty: 1-year Tool, 2-year Battery, 3-year Charger
Wireless Tool Tracking: Bluetooth
Wireless Tool Tracking: 802.15.4
Wireless Tool Tracking: 2.4 GHz Wi-Fi
Wireless Tool Tracking: 5 GHz Wi-Fi
Wireless Tool Tracking: USB-C

IR RTS140PS8-K2

RTS 1/2" 20V Mechanical Cordless Pulse Tool 2 Battery Kit, 103ft-lb Torque, 3600PPM, 2700RPM, Pin Retainer

RTS Responsive Tightening System - Transform assembly lines with the RTS Connect, where responsive action meets torque control. Infused with Ingersoll Rand® torque control algorithm, this system is a game changer for reliable tightening. Experience effortless operations with its user-friendly interface, 40 distinct torque levels, seven flush levels and dual speed non-contact trigger and a 360° status beam LED ring light. The RTS Connect features reactionless performance, combined with robust wireless connectivity and programmable settings, making it the tool of choice for those who demand perfection at every turn.

Features And Benefits

• SIMPLE: An integrated color LCD display is an easy-to-use interface that streamlines the setup process and delivers key insights to the operator. The multi-color 360° status beam LED ring light illuminates the work area and offers clear feedback to the operator on the cycle status. 3 programming methods provide faster and smarter configuration. (Basic setup via the tool display, Advanced setup via INSIGHT™ Connect controller or mobile app, Expert setup via INSIGHTqcx™ MTC controller)
• FLEXIBLE: Up to 8 P-set configurations reduce the need for multiple tools for different applications on the assembly line. Compatible with IQV20™ battery and charger platform, providing flexibility and reducing costs in operations. 4 communication options available to adapt to evolving connectivity requirements. (Wi-Fi 2.4 and 5 Ghz, Radio (802.15.4), Bluetooth, USB-C)
• CAPABLE: Proprietary torque control algorithm that delivers consistent, repeatable fastening every time. 40 torque settings and 7 flush detection levels to adapt to various application types. Multi-tool connection, with up to 16 tools wirelessly connected to the INSIGHTqcx™ MTC controller, reduces the hardware footprint.
• ERGONOMICS: RTS Connect tools eliminate torque reaction, have best-in-class tool balance & ergonomic grip design, and their light weight design significantly reduces operator fatigue.
• KIT INCLUDES: 1/2" RTS Pulse Tool, (2) 2.5 Ah Batteries, Charger.

Includes: 1/2" RTS Pulse Tool, (2) 2.5 Ah Batteries, Charger.
Product Application and Uses: For use in product environments on assembly lines.
Anvil Length: Standard
Built-in Light: Yes
Color: Grey
Configuration/Handle Type: Pistol Grip
Data Storage Capacity: 1200 cycles
Drive Size (in): 1/2
Drive Type: Square
Duty Rating: Production Environment
Fastener Size: M10-M14
Housing Material: Glass-filled Nylon (PA6-GF30)
Lumens: 11
Max Free Speed (rpm): 2700
Motor: Brushless Motor
Number of Batteries Required: 1
Power Source: Battery Powered
Product Length (in): 6.65
Product Weight (lb): 2.42
Product Weight (lb) (with Battery): 3.32
Pulses per Minute: 3600
Recommended Forward Torque Range (ft-lb): 22-103
Recommended Forward Torque Range (in-lb): 266-1239
Recommended Forward Torque Range (nm): 30-140
Retainer Type: Pin Detent
Reversible: Reversible
Sound Pressure/Power Db(A): 95 / 103
Vibration Level (m/s2): 11
Vibration Uncertainy K* (m/s2): 1.6
Voltage DC: 20
Warranty: 1-year Tool, 2-year Battery, 3-year Charger
Wireless Tool Tracking: Bluetooth
Wireless Tool Tracking: 802.15.4
Wireless Tool Tracking: 2.4 GHz Wi-Fi
Wireless Tool Tracking: 5 GHz Wi-Fi
Wireless Tool Tracking: USB-C

NTT 180244.B08

PTS-72-1350 1" Sq Dr

STR 10781

Wireless Digital Torque Wrenches: 1350 Series Digital Torque and Angle Wrench, ft-lb

Product Group	:		1350 Series Digital Torque and Angle Wrench, ft-lb
Model	:		1350 Series Exacta 2-25
Capacity (Nm)	:		33.9 Nm
Torque Range (ft.lb)	:		5-25 ft.lbf
Overall Length	:		14.88 in
Head Type	:		Pin/Spring

Product Description

• Torque Accuracy: +/-2% of the indicated value from 20% to 100% of rated capacity, +/-4% of the indicated value from 5% to 19% of rated capacity in CW and CCW directions
• Patented "Shear Beam" transducer eliminates lever sensitivity to produce more consistently accurate torque application
• Torque and Angle functionality include these operational modes: Torque To Angle, Torque and Angle Monitoring, Residual Torque, and Prevailing Torque
• Torque and angle can identify changing joint conditions and prevent errors
• The torque-only functionality includes Track and Peak modes of operation
• The backlit display is easy to read in any light condition
• Customizable color display change to inform the operator
• Display lights upon torque application; Turns yellow at 90% of target torque; Turns green upon reaching target torque; Turns red upon reaching maximum torque
• Tool emits an acceptance tone and the handle vibrates upon reaching target torque and angle values
• Tool emits reject tone upon reaching maximum torque
• Compatible with the Global 400 and Global 400mp
• P-Sets are set and saved via the controller
• No changes can be made at the wrench level, this provides you with another level of error proofing by preventing inadvertent changes
• Can be used with the Patented Holding Tool Series

STR 810153

Click-Type Preset Torque Wrenches: LTCS Preset Interchangeable Head Click-Type Torque Wrenches - Fixed Square Drive, in-lb

Product Group	:		LTCS Preset Interchangeable Head Click-Type Torque Wrenches - Fixed Square Drive, in-lb
Model	:		LTCS 7200 I
Torque Range (Nm)	:		162.6-813 Nm

Product Description

• LTCS Series torque wrenches have +/- 4% Indicated Value Accuracy from 20% to 100% of capacity, meeting or exceeding the requirements of ASME B107.300-2010 and ISO 6789
• When we preset the tool to your requested torque value we include a free Certificate of Calibration from our ISO 17025 Accredited Lab
• The low profile of the square drive creates access where other tools cannot go, which is important with our larger square drives
• Flattened case prevents side loading and provides support for the click mechanisms so the wrench is easier to calibrate and it hold calibration longer
• Cushioned comfort grip is lightweight and provides excellent ergonomics
• Slide pin ratchet provides strength and durability
• Easy to install ratchet renewal kit is available
• The torque is preset and locked in with a special tool
• Combination Adjusting and Release Tool (CART P/N 819177) allows the operator to easily adjust torque on all SLTC, LTC, LTCR and LTCS wrenches
• Torque can be set using any unit of measurement
• Can be ordered preset from the factory or you can set the torque with your own torque tester
• Wrench measures torque in the clockwise direction

STR 810410

Wireless Click-Type Torque Wrenches: SLTC FM 2.4 GHZ Click Wrenches, in-lb

Product Group	:		SLTC FM 2.4 GHZ Click Wrenches, in-lb
Model	:		SLTC FM2.4 300 I OHT A3
Torque Range (Nm)	:		34 Nm
Torque Range (in.lb)	:		60-300 in.lb
Head Type	:		Dovetail

Product Description

• Preset click torque wrench measures and applies torque in the clockwise direction
• Using this wrench in the counter-clockwise direction will apply torque, but it will not measure torque because it does not click in the counter-clockwise direction
• Flattened case for superior accuracy, reliability, and durability
• Accuracy of +/- 4% or better of preset value from 20% to 100% of capacity meets or exceeds requirements of ASME B107.300-2010 and ISO 6789
• Excellent audible/tactile impulse when preset torque is achieved
• Error Proofing By Guidance: Monitors time in the clicked position to proved OK/BAD quality attribute data with every use of the tool
• Error Proofing By Behavior Modification in action. The new A3 has a new battery that lasts longer and is easier to change
• Raised LED Fresnel to improve visibility when working in less than optimal positions
• AAA batteries are more readily available than are the 6-volt batteries

STR 810420

Wireless Click-Type Torque Wrenches: SLTC FM 2.4 GHZ Click Wrenches, in-lb

Product Group	:		SLTC FM 2.4 GHZ Click Wrenches, in-lb
Model	:		SLTC FM2.4 3000 I A3
Torque Range (Nm)	:		339 Nm
Torque Range (in.lb)	:		600-3000 in.lb
Head Type	:		Dovetail

Product Description

• Preset click torque wrench measures and applies torque in the clockwise direction
• Using this wrench in the counter-clockwise direction will apply torque, but it will not measure torque because it does not click in the counter-clockwise direction
• Flattened case for superior accuracy, reliability, and durability
• Accuracy of +/- 4% or better of preset value from 20% to 100% of capacity meets or exceeds requirements of ASME B107.300-2010 and ISO 6789
• Excellent audible/tactile impulse when preset torque is achieved
• Error Proofing By Guidance: Monitors time in the clicked position to proved OK/BAD quality attribute data with every use of the tool
• Error Proofing By Behavior Modification in action. The new A3 has a new battery that lasts longer and is easier to change
• Raised LED Fresnel to improve visibility when working in less than optimal positions
• AAA batteries are more readily available than are the 6-volt batteries

STR 810424

Wireless Click-Type Torque Wrenches: SLTC FM 2.4 GHZ Click Wrenches, in-lb

Product Group	:		SLTC FM 2.4 GHZ Click Wrenches, in-lb
Model	:		SLTCR-2.4FM-1800I-A3
Torque Range (Nm)	:		203.73 Nm
Torque Range (in.lb)	:		360-1800 in.lb
Head Type	:		Ratcheting

Product Description

• Preset click torque wrench measures and applies torque in the clockwise direction
• Using this wrench in the counter-clockwise direction will apply torque, but it will not measure torque because it does not click in the counter-clockwise direction
• Flattened case for superior accuracy, reliability, and durability
• Accuracy of +/- 4% or better of preset value from 20% to 100% of capacity meets or exceeds requirements of ASME B107.300-2010 and ISO 6789
• Excellent audible/tactile impulse when preset torque is achieved
• Error Proofing By Guidance: Monitors time in the clicked position to proved OK/BAD quality attribute data with every use of the tool
• Error Proofing By Behavior Modification in action. The new A3 has a new battery that lasts longer and is easier to change
• Raised LED Fresnel to improve visibility when working in less than optimal positions
• AAA batteries are more readily available than are the 6-volt batteries

STR 815700

Beam & Dial Torque Wrenches: Dial Torque Wrenches, in-lb

Product Group	:		Dial Torque Wrenches, in-lb
Model	:		IDW 30I FINAL ASSY
Torque Range	:		6-30 lbf in
Scale	:		1 lbf in
Weight	:		1.2 lb
OAL	:		10.3 in

Product Description

• Accuracy of +/- 3% Indicated Value from 20% to 100% of capacity
• Meets or exceeds ASME B107.300-2010 and ISO 6789
• Includes free Certificate of Calibration from our ISO 17025 Accredited Lab
• Error Proofing By Design: Oversized dial face is extremely easy to read and helps to eliminate parallax error
• Glare-resistant dial cover makes it easy to read in difficult light conditions
• Error Proofing By Design: A memory indicator is provided on each wrench and remains at the maximum torque achieved for positive torque verification
• Heavy-duty dial guard protects against breakage
• Dial faces are color-coded: silver for inch-pounds, gold for foot-pounds, and white for Newton meters
• Wrenches with a capacity of up to 50 ft-lbs have a black powder-coated handle that provides an industrial-strength finish
• Wrenches with a capacity of 175 to 250 ft-lbs have a flexible PVC handle. The flexible PVC grip that comes on tools up to 250 ft. lbs. supports proper grip and provides comfort during use
• Wrenches with a capacity of 600 to 1000 ft-lbs have a specially designed extension aluminum handle that is easy to grip
• Each wrench comes in its own rugged, blow-molded, storage case
• FREE NIST-traceable tabulated certification included.

STR 815719

Beam & Dial Torque Wrenches: Dial Torque Wrenches, in-lb

Product Group	:		Dial Torque Wrenches, in-lb
Model	:		IDW 50I FINAL ASSY
Torque Range	:		10-50 lbf in
Scale	:		2 lbf in
Weight	:		1.2 lb
OAL	:		10.3 in

Product Description

• Accuracy of +/- 3% Indicated Value from 20% to 100% of capacity
• Meets or exceeds ASME B107.300-2010 and ISO 6789
• Includes free Certificate of Calibration from our ISO 17025 Accredited Lab
• Error Proofing By Design: Oversized dial face is extremely easy to read and helps to eliminate parallax error
• Glare-resistant dial cover makes it easy to read in difficult light conditions
• Error Proofing By Design: A memory indicator is provided on each wrench and remains at the maximum torque achieved for positive torque verification
• Heavy-duty dial guard protects against breakage
• Dial faces are color-coded: silver for inch-pounds, gold for foot-pounds, and white for Newton meters
• Wrenches with a capacity of up to 50 ft-lbs have a black powder-coated handle that provides an industrial-strength finish
• Wrenches with a capacity of 175 to 250 ft-lbs have a flexible PVC handle. The flexible PVC grip that comes on tools up to 250 ft. lbs. supports proper grip and provides comfort during use
• Wrenches with a capacity of 600 to 1000 ft-lbs have a specially designed extension aluminum handle that is easy to grip
• Each wrench comes in its own rugged, blow-molded, storage case
• FREE NIST-traceable tabulated certification included.

STR 850227

Beam & Dial Torque Wrenches: Flat and Tapered Beam Torque Wrenches, ft-lb

Product Group	:		Flat and Tapered Beam Torque Wrenches, ft-lb
Model	:		M 300
Torque Scale	:		300 lbf ft
Square	:		10 lbf ft
Weight	:		10.75 lb

Product Description

• Incredibly durable design
• Exceptional accuracy retention permits extended calibration intervals and extremely low ownership cost
• Flat and Tapered Beam torque wrenches have a very low cost of ownership; they are virtually maintenance and repair-free
• Pivoted handle concentrates load at a precise point on the lever to assure torque accuracy
• Memory feature consists of pointers that follow a track on the scale and remain in place to indicate peak torque achieved
• Peak torque indicated on the scale is accurate even in destructive applications
• Bi-directional accuracy of +/- 2% of Indicated Value from 20% to 100% of capacity meets or exceeds requirements of ASME B107.300-2010 and ISO 6789
• Includes FREE certificate of calibration from our +/- .25% Indicated Value accuracy/ISO/IEC 17025 Accredited Calibration Laboratory

STR 869756

Micrometer Adjustable Torque Wrenches: SDR Series Micrometer Adjustable Click Wrench, ft-lb

Product Group	:		SDR Series Micrometer Adjustable Click Wrench, ft-lb
Model	:		3SDR 75 MG
Torque Range (ft.lb)	:		15-75 lbf ft
Scale (lb)	:		0.5 lbf ft
Square Drive	:		3/8 in
Weight (lb)	:		1.5 lb

Product Description

• Adjust torque value by rotating the grip
• Grip lock makes locking in torque value fast, easy, and secure
• Tool changees from one end of the scale to the other with the fewest number of turns
• Ball-bearing rock-over assembly assures smooth operation enhances repeatability and increases wrench service life
• Accuracy of +/- 4% of Indicated Value from 20% to 100% of rated capacity
• Meets or exceeds requirements of ASME B107.300-2010 and ISO 6789
• Error Proofing By Guidance design provides a strong audible and tactile impulse when the set torque is achieved
• Error Proofing By Design flattened case provides the mechanism with superior support resulting in a wrench that is easier to calibrate and one that holds calibration longer
• Flattened case prevents side loading during torque application or testing/calibration
• Knurled grip offers an ergonomic grip that remains comfortable over long periods of use
• Ratchet is built for durability
• Ratchet replacement is fast and easy when needed
• All tools up to 250 ft-lb capacity come with a rugged, custom-molded plastic case
• Includes FREE tabulated calibration certificate from our ISO 17025 certified calibration laboratory

STR 869766

Micrometer Adjustable Torque Wrenches: CCM Micrometer Adjustable Click Wrenches, in-lb

Product Group	:		CCM Micrometer Adjustable Click Wrenches, in-lb
Model	:		CCM 750I MG
Torque Range (in.lb)	:		150-750 lbf in
Scale (in)	:		5 lbf in
Overal Length	:		13.8 in

Product Description

• Accuracy of +/-4% of Indicated Value from 20% to 100% of the rated capacity
• Meets or exceeds the requirements of ASME B107.300-2010 and ISO 6789
• SR Dovetail connects with all of our interchangeable heads
• Every one of our interchangeable heads fits on every one of our wrenches
• No need to buy multiple wrenches and heads to cover all fastener sizes within a given torque range
• Error Proofing By Guidance: Strong audible and tactile impulse when set torque value is achieved
• Knurl Grip handle is rugged and comfortable in your hand for long periods of time
• Fast adjustment: These wrenches need the fewest number of rotations to move up and down the scale
• Error Proofing By Design: Spring tension on these wrenches can be reduced without the wrench falling out of tolerance
• Includes FREE certification from our +/-.25% Indicated Value ISO/IEC 17025 Accredited Calibration Laboratory
• Open End head sizes go from 1/4" to 1 1/4" (or 5 mm to 32 mm) with our 1 7/16" (36.5 mm) common centerline
• Open End head sizes from 1 5/16" to 3 1/4" (or 34 mm to 60 mm) maintain the 3 7/8" (98.4 mm) common centerline
• All wrenches with a capacity over 150 ft. lbs. or 200 Nm are calibrated with interchangeable heads having a common centerline of 3 7/8 inches (98.4 mm)

STR 874013

Click-Type Preset Torque Wrenches: BLT Bidirectional Preset Click-Type Torque Wrenches, in-lb

Product Group	:		BLT Bidirectional Preset Click-Type Torque Wrenches, in-lb
Model	:		BLT 750 I
Torque Range (Nm)	:		17-85 Nm

Product Description

• SR Dovetail Head connects to over 100 SR Interchangeable Heads
• Error Proofing By Design: the SR Dovetail transmits the load at a right angle from the wrench to the head, providing exceptional strength and rigidity of the connection
• A pin lock on the dovetail assures positive head connection, yet permits head changeover in seconds
• CW +/- 4% Indicated Value Accuracy and CCW +/- 6% Indicated Value Accuracy from 20% to 100% of capacity, meeting or exceeding the requirements of ASME B107.300-2010 and ISO 6789
• we preset the tool to your requested torque value and we include a Certificate of Calibration from our ISO 17025 Accredited Lab
• Error Proofing By Behavior Modification: excellent tactile and audible pulse when the preset torque is achieved
• Error Proofing By Design: the flattened case prevents side-loading and ensures greater accuracy and durability
• Comfortable cushion grip plus light-weight for excellent ergonomics
• Preset and locked in with a special CART tool
• Torque can be set using any unit of measurement
• Can be ordered preset from the factory or you can set the torque with your own torque tester
• All of our tools provide torque measurements in the clockwise direction
• BLT preset click wrench measures torque in both clockwise and counterclockwise directions

IR IQI4LT0500PQ4

IQI 1/4" Quick Change Inline Screwdriver, Transducerized Control, Push-to-Start, 900 RPM, 2-5 Nm

Ingersoll Rand® IQi Series, is an inline low torque electric screwdriver offering available in transducerized and current control configurations. Customers will experience increased efficiency with faster set up, automated workflows and remote system access, while improving quality through advanced fastening strategies, real-time data traceability and the industry’s first tilt angle control. From high-volume assembly to quality-critical manufacturing, IQi Series delivers unmatched efficiency, precision and reliability at a reduced total cost of ownership.

Features And Benefits

• Increase Efficiency: Reduce setup time up to 50% by reducing costly workflow interruptions with an intuitive web-based interface that eliminates the need for manual controller adjustments. Rapid deployment ensures seamless operational readiness. Seamless MES and Fieldbus integration automates tool and job selection, reducing manual errors and improving uptime. Operators can focus on high-value tasks for increased efficiency.
• Maximize Productivity: With real-time traceability, live access to production data enhances continuous quality control, enabling quick issue identification and resolution to improve productivity and compliance. Program, troubleshoot, and monitor systems remotely. Real-time adjustments from anywhere reduce the on-site presence and operational costs while enhancing scalability for production teams.
• Improve Quality: Achieve fastening precision with ±3.5% accuracy on transducerized models to minimize assembly errors and significantly lower rework costs with precise torque and angle control, ensuring consistent, high-quality results. Improve assembly quality with the industry-leading tilt angle control that ensures precise tool alignment, prevents cross-threading, and maintains optimal joint integrity.
• Reduce Total Cost: Designed to withstand over 1 million maintenance-free cycles, reducing maintenance frequency and downtime for long-term operational efficiency. The robust design and durable brushless motors extend tool lifespan, minimizing replacement needs and lowering total cost of ownership.

Actuation/Throttle Type/Switch Type: Push to Start
Anvil Length: Standard
Built-in Light: Yes
Color: Black
Configuration/Handle Type: Straight
Drive Size (in): 1/4
Drive Type: Hex
Max Free Speed (rpm): 900
Max Torque (ft-lb): 3.7
Max Torque (in-lb): 44
Max Torque (nm): 5
Motor: Brushless Motor
Power Source: Electric
Product Length (in): 10.7087
Product Weight (lb): 1.9383259911894273
Recommended Forward Torque Range (ft-lb): 1.5-3.7
Recommended Forward Torque Range (in-lb): 18-44
Recommended Forward Torque Range (nm): 2-5
Retainer Type: Quick Change
Reversible: Reversible
Sound Pressure/Power Db(A): < 70
Vibration Level (m/s2): < 2.5
Warranty: 1-year
Wireless Tool Tracking: No Wireless Functionality
Wireless Tool Tracking: USB-A

IR IQI4LT1500PQ4

IQI 1/4" Quick Change Inline Screwdriver, Transducerized Control, Push-to-Start, 300 RPM, 5-15 Nm

Ingersoll Rand® IQi Series, is an inline low torque electric screwdriver offering available in transducerized and current control configurations. Customers will experience increased efficiency with faster set up, automated workflows and remote system access, while improving quality through advanced fastening strategies, real-time data traceability and the industry’s first tilt angle control. From high-volume assembly to quality-critical manufacturing, IQi Series delivers unmatched efficiency, precision and reliability at a reduced total cost of ownership.

Features And Benefits

• Increase Efficiency: Reduce setup time up to 50% by reducing costly workflow interruptions with an intuitive web-based interface that eliminates the need for manual controller adjustments. Rapid deployment ensures seamless operational readiness. Seamless MES and Fieldbus integration automates tool and job selection, reducing manual errors and improving uptime. Operators can focus on high-value tasks for increased efficiency.
• Maximize Productivity: With real-time traceability, live access to production data enhances continuous quality control, enabling quick issue identification and resolution to improve productivity and compliance. Program, troubleshoot, and monitor systems remotely. Real-time adjustments from anywhere reduce the on-site presence and operational costs while enhancing scalability for production teams.
• Improve Quality: Achieve fastening precision with ±3.5% accuracy on transducerized models to minimize assembly errors and significantly lower rework costs with precise torque and angle control, ensuring consistent, high-quality results. Improve assembly quality with the industry-leading tilt angle control that ensures precise tool alignment, prevents cross-threading, and maintains optimal joint integrity.
• Reduce Total Cost: Designed to withstand over 1 million maintenance-free cycles, reducing maintenance frequency and downtime for long-term operational efficiency. The robust design and durable brushless motors extend tool lifespan, minimizing replacement needs and lowering total cost of ownership.

Actuation/Throttle Type/Switch Type: Push to Start
Anvil Length: Standard
Built-in Light: Yes
Color: Black
Configuration/Handle Type: Straight
Drive Size (in): 1/4
Drive Type: Hex
Max Free Speed (rpm): 300
Max Torque (ft-lb): 11
Max Torque (in-lb): 133
Max Torque (nm): 15
Motor: Brushless Motor
Power Source: Electric
Product Length (in): 10.7087
Product Weight (lb): 1.9383259911894273
Recommended Forward Torque Range (ft-lb): 3.7-11
Recommended Forward Torque Range (in-lb): 44-133
Recommended Forward Torque Range (nm): 5-15
Retainer Type: Quick Change
Reversible: Reversible
Sound Pressure/Power Db(A): < 70
Vibration Level (m/s2): < 2.5
Warranty: 1-year
Wireless Tool Tracking: No Wireless Functionality
Wireless Tool Tracking: USB-A

IR QE2SL002P10Q04

QE2 DC FASTENING IN-LINE LEVER. 2 NM

IR QE2SL010PM0

QE2 DC FASTENING IN-LINE LEVER. 10 NM

IR QE2TS002P11Q04

ASSEMBLY TOOL QE2TS002P11Q04

IR QE2TS007P11Q04

ASSEMBLY TOOL QE2TS007P11Q04

IR QE8AT150RA6S08

Assembly Tool, Trigger Start, 150NM, RXN Spline Mount

IR QE8ST230F62S12

DC Tool, 23-230 Nm, 3/4in Sq.Dr., 150 MM Spindle
